Cummins generator set configuration

PUBLIC PRODUCT PATHWAY

Cummins diesel generator sets

EngineCumminsPower range10–200 kVA · 200–500 kVA · 500–1000 kVA · 1000–2000 kVA · Above 2000 kVAFrequency50HZ · 60HZ
  • Review Cummins engine-based generator-set configurations for commercial, industrial, infrastructure and backup-power requirements.
  • Use the captured specification tables to compare model, power, engine and dimension fields for the selected frequency.
  • For project selection, confirm the applicable power range, generator type, frequency, voltage, cooling arrangement and control system with the quotation.
  • Options such as ATS, silent enclosure, trailer or containerized packaging depend on the selected configuration and site requirements.
TEL: +86 190 7413 9768Mail: eric@kashifer.com
Ask for Technical Data

50HZ

Genset ModelStandby kVAStandby kWPrime kVAPrime kWEngine ModelDimension (MM) L×W×H
Focus-C30302427224B3.9-G21800*850*1300
Focus-C44443540324BT3.9-G21800*900*1400
Focus-C69695562.5504BTA3.9-G21800*900*1400
Focus-C70705665524BTA3.9-G21800*900*1400
Focus-C90907280644BTA3.9-G111900*800*1400
Focus-C110A11088100804BTA3.9-G131900*800*1400
Focus-C110B11088100806BT5.9-G22200*900*1450
Focus-C125125100113906BT5.9-G22200*900*1450
Focus-C1381381101251006BTA5.9-G22300*900*1450
Focus-C1501501201381106BTAA5.9-G22350*1000*1550
Focus-C1751751401601286BTAA5.9-G122500*1000*1550
Focus-C2002001601801456CTA8.3-G22500*900*1560
Focus-C2152151722001606CTAA8.3-G22600*900*1560
Focus-C2642642112502006LTAA8.9-G22600*1000*1600
Focus-C2752752202502006LTAA8.9-G32600*1000*1600
Focus-C3003002402702206LTAA9.5-G32700*1100*1700
Focus-C313313250275220NTA855-G1A2600*1600*1500
Focus-C340A3402723132506LTAA9.5-G12700*1100*1700
Focus-C340B340272313250NTA855-G1B3000*1100*1700
Focus-C375375300350280NTA855-G2A3000*1100*1700
Focus-C388388310350280NTA855-G43000*1100*1700
Focus-C413413330375300NTAA855-G73300*1250*1850
Focus-C4254253403883106ZTAA13-G33000*1300*1700
Focus-C438438350400320QSNT-G32900*1250*1900
Focus-C4754753804383506ZTAA13-G43000*1300*1800
Focus-C500500400450360KTA19-G33400*1400*1900
Focus-C513513410500400QSZ13-G33100*1250*1850
Focus-C550550440500400QSZ13-G103300*1450*1900
Focus-C563A563450500400KTA19-G3A3400*1400*2000
Focus-C563B563450500400KTA19-G43400*1450*2000
Focus-C625625500563450KTAA19-G53600*1460*2100
Focus-C688688550KTAA19-G6A3700*1500*2200
Focus-C800800640725580KT38-GA4450*1700*2360
Focus-C825825660750600KTA38-G24450*1700*2360
Focus-C888888710800640KTA38-G2B4450*1700*2360
Focus-C10001000800910728KTA38-G2A4450*1700*2360
Focus-C110011008801000800KTA38-G54400*1800*2400
Focus-C125012501000KTA38-G94800*1800*2500
Focus-C13751375110012501000KTA50-G35200*2000*2500
Focus-C16501650132013751100KTA50-G85900*2270*2500
Focus-C18751875150016751340KTA50-G15X6200*2300*2550
Focus-C20902090165020001600KTA50-G16B6200*2300*2550

CONFIGURATION REVIEW

Continue the configuration review

Use a small number of related pathways to compare the selected requirement. Final fit, availability and commercial scope are confirmed in the quotation.

all engine pathwaysReturn to the engine selection hub.10–200 kVA rangeReview the captured rating pathway supported by the table.200–500 kVA rangeReview the captured rating pathway supported by the table.send your generator requirementsMove from the selected pathway to an RFQ review.

WHY KASHIFER

Built around a complete power solution

Selection is clearer when technical data, configuration scope and commercial terms are reviewed together.

KASHIFER reviews the application, load profile, power rating, structure and operating requirements before quotation.

Technical tables keep the captured model, power, engine, frequency and dimension fields visible for procurement review.

Supplier-supported production, testing, inspection and packaging capabilities are confirmed for the selected project.

OEM/ODM scope, availability, delivery, warranty and trade terms are confirmed in the quotation and contract.

Discuss your requirement

Send the requirement for server-side validation and configuration review.

We use these details only to review and respond to this inquiry. They are sent to KASHIFER's inquiry system and designated notification recipient; no browser storage is used.

FAQ

Frequently asked questions

What information should I send for a quotation?
Share the application, required power, frequency, voltage, operating mode, structure, delivery location and any control, ATS, trailer or container requirements.
What power ranges are available?
The public catalog is organized into 10–200 kVA, 200–500 kVA, 500–1000 kVA, 1000–2000 kVA and above 2000 kVA pathways. Confirm the selected model and rating in the technical table and quotation.
Which engine brands can be reviewed?
The catalog includes Cummins, Perkins, Volvo, Mitsubishi, Doosan, Weichai and Yuchai pathways. Availability, pairing and final configuration depend on the project and quotation.
Can I request silent, open, trailer or containerized equipment?
Yes. Open, silent, mobile trailer and containerized formats can be reviewed against installation, transport, noise, protection and maintenance requirements.
Do you support OEM or ODM requirements?
OEM & ODM support is available for approved requirements including branding, enclosure, color, voltage, frequency, control system, ATS, trailer, container and packaging. Final scope is confirmed in the quotation and contract.
What is the minimum order quantity?
Minimum Order Quantity: 1 Set.
What are the payment terms?
Payment is by T/T. Standard arrangements include 100% advance payment or 30% deposit with the balance payable before shipment/delivery, subject to quotation and contract.
What is the typical delivery time?
Typical lead time is 7–15 days depending on configuration and order requirements. It is subject to order confirmation and is not a fixed promise for every order.
What warranty is provided?
Standard 1-year warranty. Extended engine or alternator coverage may depend on the selected brand and configuration; consumables and normal wear items are excluded. Final terms are subject to the sales contract.
Can you provide shipping and technical documentation?
Shipping documentation and technical information can be coordinated for the approved configuration. Destination-market requirements and final document scope are confirmed during quotation and order coordination.
